Product Details:
|
| Standard: | ECG, SPO2, NIBP, Temp, PR/HR | Warranty: | 24 Months |
|---|---|---|---|
| Screen Size: | 12.1 Inch TFT LCD | Packing: | Export Carton |
| Function: | Monitor, Diagnostic, Operation | Original: | P.R.China |
| Net Weight: | 5.3 KGs | Dimension: | 300.0 X 170.00 X 305.00mm |
| Highlight: | NIBP Portable Patient Monitor,SPO2 Portable Patient Monitor,ECG Portable Vital Signs Monitor |
||
Portable Patient monitor with Vital Signs patient monitor hospital patient monitor multi para meter ECG SPO2 NIBP Temp
12.1" Portable Multi parameter Patient Monitor general ward and clinic monitoring bedside cardiac monitor Beta 12S
Portable Patient Monitor Quick Details:
Standard Functions
Hung-Kee Patient monitor Brochure 2022.01.pdf
Portable Patient Monitor Technical details:
Table ECG Specifications
| Parameter | Specifications |
| Heart ratemeter accuracy andresponse to irregular rhythm |
Ventricular bigeminy: 80 bpm±2bpm Slow alternating ventricular bigeminy:60 bpm ±2bpm Rapid alternating ventricularbigeminy: 120 bpm ±2bpm Bidirectional systoles: 90 bpm±2bpm |
| Response time of heart ratemeter to change in heartrate |
HR change from 80 bpm to 120 bpm: ≤ 8 smaximum HR change from 80 bpm to 40 bpm: ≤ 10 s maximum |
| Time to alarm for tachycardia |
Vent tachycardia (1 mVpp, 206 bpm): Gain 0.5, range 6.5 to 8.4s, average 7.2s Gain 1.0, range 6.1 to 6.9s, average 6.5s Gain 2.0, range 5.9 to 6.7s, average 6.3s Vent tachycardia (2 mVpp, 195 bpm): Gain 0.5, range 5.4 to 6.2s, average 5.8s Gain 1.0, range 5.7 to 6.5s, average 6.1s Gain 2.0, range 5.3 to 6.1s, average5.7s |
| ECG analog output | 0.67 Hz - 40 Hz |
| Time to alarm for high heartrate | ≤10s |
| Time to alarm for low heart rate | ≤10s |
( for more detailed technical data please refer to above PDF brochure)
Portable Patient Monitor Description:
The Beta 12S portable patient monitor is part of Hung-Kee’s premier patient monitoring solution designed to enhance patient care and support timely and accurate clinical assessment across general ward, daily checking and clinic environments. This portable patient monitor designed with basic parameters like ECG, RESP, TEMP, NIBP, SpO2 and PR , and for meeting specific clinic demand extra parameters EtCO2, 2-Ch IBP, C.O., Masimo SPO2, Suntech NBIP, printer and touch are developed.
This portable patient monitor, power supplied by 100-240V~,50/60Hz, adopts 12.1'' color TFT LCD displaying real-time date and waveform. It can synchronously display seven-channel waveform and full monitoring parameters equipped with an optional 48mm thermal recorder. Maximum 64 units portable patient monitor could be connected to the central monitoring system via wire network to form a network monitoring system.
Portable Patient Monitor Standard Accessories:
5-lead ECG cable, SPO2 sensor, BP cuff, Temperature probe, Lithium battery, User manual, Power cord
Portable Patient Monitor Optional Accessories:
Aluminum trolley, wall mount stand
FAQ for Portable Patient Monitor:
1.Q: How long is the warranty time?
A: 24 Months
2. Q: When do you delivery?
A: Usually in 7-30 days depends on the order qty and available of some specific parts.
3. Q: Could you accept OEM order?
A: Yes, OEM and ODM are our main business.
4.Q: Do you work on SKD project?
A: Yes, we have more than 14 years experience on SKD service, full assembling procedure will be provided, and detailed guidance of local assembling work will be offered.
5. Q: Can I order a sample?
A: Sure, delivery sample by global express in charge.
