Product Details:
|
| Standard: | ECG, NIBP, SPO2, 2Temp, PR/HR | Language: | English, Russia, Spanish, French, Polish, Portuguese, Turkey |
|---|---|---|---|
| SKD/OEM/ODM: | Acceptable | Functions: | Monitor, Diagnostic, Operation |
| Application: | Adult, Child, Neonate | Transport Package: | Export Carton |
| Option1: | CMS, Touch, Printer, Masimo SPO2 | Option2: | 2IBP, C.O., EtCO2, Suntech NIBP |
| Trade Terms: | CIF, Exworks | Payment Terms: | TT |
| Highlight: | SPO2 Modular Patient Monitor,ECG Modular Patient Monitor,Cardiac ICU Vitals Monitor |
||
Modular patient monitor neonate patient monitor ICU cardiac monitor portable patient monitor neonate patient monitor
12.1" Portable Modular Patient Monitor general ward and clinic monitoring cardiac patient monitor Beta 12Plus
Modular Patient Monitor Quick Details:
| Optional | Touch Screen, Printer, 3/12-lead ECG, single/double IBP, double Temp., SunTech NIBP, Masimo Spo2, ETCO2, CO; |
| Multi-display interface | Standard, Large font, Trend Coexist, OxyCRG dynamic, 7 full ECG waveforms; |
| Language | Built-in 8 language for choose (English, Chinese, Turkish, Spanish, French, Russian, Portuguese, Italian); |
| Review | Maximum 168h tabular and graphic trends of all parameters, 400NIBP records and 60 alarm event; |
| Fanless | Use special fanless cooling technology in the device to provide a quiet environment for users; |
| Analysis | Real time S-T segment analysis, and 20 types of arrhythmic analysis; SpO2 Pitch Tone Variation, Drug Dose Calculation and Hemodynamic Calculations; |
| Resistance to interference | Efficient resistance to interference of defibrillator and HF knife; |
Hung-Kee Patient monitor Brochure 2022.01.pdf
Modular Patient Monitor Technical details:
| Display size | 12.1''color TFT LCD |
| ECG sensitivity | > 200 µV (peak-peak date ) |
| Lead selection |
Standard 3 lead or 5 lead cable 3 lead RA,LA,LL,lead method:I,II,III 5-lead RA,LA,LL,RL,V,lead method:I,II,III,aVR,aVL,aVF,V |
| ST measurement |
Range: -2.5mV ～ +2.5mV Measurement accuracy: within -0.8 mV～+0.8mV, the tolerance is ±0.02mVor ±10% Without this range, there is no definition |
| SpO2 Measuring Range | 0 ~ 100 % |
| TEMP Measuring and Alarm Range | 0 ~ 50° C |
| EtCO2 measurement | Side stream or main stream |
| EtCO2 Measurement Range | 0% to 20% (0 to 150mmHg) |
| EtCO2 Accuracy | ±2 mm Hg @ < 5.0% CO2 (at BTPS) < 10% of reading @ > 5.0%CO2(at BTPS) |
| Respiration Rate Range | 3 to 150 Breaths Per Minute (BPM) |
| Respiratory Rate Accuracy | 1% of reading ±1 breath |
( for more detailed technical data please refer to above PDF brochure)
Modular Patient Monitor Description:
The Beta 12Plus modular portable patient monitor designed to enhance patient care and support timely and accurate clinical assessment across general ward, daily checking and clinic environments.
1. Thinner and lighter in design, convenient and portable for users
2. Real-time S-T segment analysis, pacemaker detection
3. Various interfaces: standard screen, trend screen, oxy CRG screen, big front screen.
4. 3-level audio/visual alarms. Efficient resistance to interference of defibrillator and HF knife.
Modular Patient Monitor Standard Accessories:
5-lead ECG cable, SPO2 sensor, BP cuff, Temperature probe, Lithium battery, User manual, Power cord
Modular Patient Monitor Optional Accessories:
Aluminum trolley, wall mount stand
FAQ for Portable Patient Monitor:
1.Q: How long is the warranty time?
A: 24 Months
2. Q: When do you delivery?
A: Usually in 7-30 days depends on the order qty and available of some specific parts.
3.Q: Do you work on OEM and SKD project?
A: Yes, we have more than 14 years experience on OEM and SKD service, full assembling procedure will be provided, and detailed guidance of local assembling work will be offered.
4. Q: Can I order a sample?
A: Sure, delivery sample by global express in charge.
5.Q:Do You Need Foreign Agent?
A: Surely Yes, We Warmly Welcome Foreign Clients To Be our Agent.
6.Q:How Can We Guarantee Quality?
A: Each Production Step Has Two Times Inspection, Engineers Simulating Actual Operation Of Each Machine Before Shipping.
7.Q:Why Should We Buy From You Rather than from other suppliers?
A: Producing Stable Quality And Affordable Products Is Our Purpose! Hung-Kee has been producing medical devices for more than 14 years, we have rich experience in production and maintenance.
