Product Details:
|
| Standard Parameter: | ECG, NIBP, SPO2, 2Temp, PR/HR | Net Weight: | 4.00 KGs |
|---|---|---|---|
| Option 1: | 2IBP, AG, EtCO2, Masimo SPo2, Printer, 2IBP | Option 2: | Center Monitoring System, Suntech NIBP, Touch |
| Type: | Patient Monitor,Medical Monitor | Warranty Period: | 24 Months |
| Product Name: | Heart Monitor Machine | ||
| Highlight: | Ambulance Cardiac Patient Monitor,Cardiac Patient Monitor Portable,ICU Ambulance Patient Monitor |
||
Cardiac patient monitor Modular Patient Monitor multi parameter patient monitor neonate patient monitor
12.1” Portable high acuity Multi-parameter Patient Monitor ICU/OR monitoring cardiac monitor HighAcuity T12
Cardiac Patient Monitor Quick Details:
1. 12.1 inch TFT LCD screen, 6 standard parameters
2. 32-levels sound volume adjustment
3. 10-levels brightness adjustment
4. Maximum 168 hours graphic and tabular trends of all parameters;
5. ST Segment/Arrhythmia Analysis, Tabular Trending/Graphical Trending, Drug Calculations, OXY CRG
6. Maximum 20 hours continual working time (optional)
7. Touch screen (optional)
Hung-Kee Patient monitor Brochure 2022.01.pdf
Cardiac Patient Monitor Technical details:
Table IBP Specifications
| Parameter | Specification |
| IBP range |
ART 0 - 300 mmHg PA -6 - 120 mmHg CVP -10 - 40 mmHg RAP -10 - 40 mmHg LAP -10 - 40 mmHg ICP -10 - 40 mmHg |
| IBP accuracy | 1 mmHg or 2%, whichever is greater |
| Unit | mmHg or kPa |
| Sampling rate | 62.5 times per second |
| Waveform speed | 6.25 mm/s, 12.5 mm/s, 25.0 mm/s |
| Transducer sensitivity (Intellivue:Input sensitivity) | 5 uV/V/mmHg |
| Resolution | 1 mmHg (0.13 kPa) |
| Transducer type | Disposable |
( for more detailed technical data please refer to above PDF brochure)
Cardiac Patient Monitor Description:
1. New high-precision cardiac patient monitor
2. 12.1" color TFT display, up to 7 waveforms
3. Arrhythmia analysis, ST calculation, Pace analysis
4. Various interfaces: A single guide, standard, large font, all leads
5. Anti-ESU, anti- defibrillator
6. Thinner and lighter in design, convenient and portable for users
7. Real-time S-T segment analysis, pacemaker detection
Cardiac Patient Monitor Standard Accessories:
5-lead ECG cable, SPO2 sensor, BP cuff, Temperature probe, Lithium battery, User manual, Power cord
Cardiac Patient Monitor Optional Accessories:
Aluminum trolley, wall mount stand
FAQ for Cardiac Patient Monitor:
1.Q: How long is the warranty time?
A: 24 Months
2. Q: Can the accessories be exchanged around Hung-Kee devices?
A: Yes, it is possible to use the same accessories to exchange Hung-kee devices among the same series.
3. Q: When do you delivery?
A: Usually in 7-30 days depends on the order qty and available of some specific parts.
4.Q: Do you work on OEM and SKD project?
A: Yes, we have more than 14 years experience on OEM and SKD service, full assembling procedure will be provided, and detailed guidance of local assembling work will be offered.
5.Q:Can the monitors display wave-forms and numerical data?
A: Yes, can display wave-forms and numerical data.
6. Q: Can I order a sample?
A: Sure, delivery sample by global express in charge.
7.Q:How many waveforms can be displayed on the screen?
A: The screen can display up to a maximum of 7 wave-forms.
